Circular Connectors
MIL-C-26482 I Series
Our MIL-C-26482 I series connectors are ideal for circuit signal connections.

Unlock the Potential of MIL-C-26482 I Series Connectors with Raineon
Our MIL-C-26482 I series connectors are ideal for circuit signal connections.
General Information
- •Compliant with MIL-C-26482 I series standards
- •Bayonet coupling quick connect mechanism
- •Contact configuration: mostly solder-type
Main Technical Information
- •Compact size with high contact density
- •Widely used in various military and civilian equipment
Applications of Circular Connectors
Our MIL-C-26482 I series connectors are ideal for circuit signal connections.
Environments
Our MIL-C-26482 I series connectors are suitable for a wide range of military and civilian equipment, ensuring reliable electrical connections in various demanding environments featuring high humidity, salt spray, fungi, heavy rain, and dust.
Main Technical Performance
Mechanical Performance
- •Shell material: Aluminum alloy
- •Plating options:
- -Unmarked: Olive drab cadmium plating, conductive shell
- -Class L: Chemical nickel plating, conductive shell
- -Class A: Black anodization, non-conductive shell
- -Class B: Cadmium plating, conductive shell
- -Class S: Stainless steel passivation, conductive shell
- -Class BW: Cadmium plating, brownish-green color, conductive shell
- •Insulator material: Thermosetting or thermoplastic
- •Sealing material: Silicone rubber
- •Contact material: Gold-plated copper alloy
- •Mechanical lifespan: 500 mating cycles
- •Shock resistance: Withstands acceleration up to 490m/s²
- •Random vibration resistance: Frequency range of 10-2000Hz, acceleration of 147m/s²
Electrical Performance
Contact Resistance and Current Rating
| Contact No. | Diameter (mm) | Resistance(mΩ) | Current (A) |
|---|---|---|---|
| 20# | Ø1.00 | ≤5 | 7.5 |
| 16# | Ø1.60 | ≤2.5 | 13 |
| 12# | Ø2.40 | ≤1.5 | 23 |
Working voltage and withstanding voltage (V):
| Service rating | Withstanding voltage | Withstanding voltage | ||
|---|---|---|---|---|
| I | II | I | II | |
| Sea level | 1000 | 600 | 1500 | |
| 21336m | 450 | 300 | 375 | |
Insulation resistance: ≥ 5000MΩ at 25°C, and ≥ 3MΩ at 125°C
Sealing:
Wire sealing: Pressure difference of 2×105Pa, leakage rate less than 4.6×102Pa·cm³/s
Sintered sealing: Pressure difference of 1×105Pa, leakage rate less than 0.1Pa·cm³/s
Environmental Performance
- •Operating temperature: -55°C to +125°C
- •Relative humidity: 95±4% at 40°C
- •Salt spray test results:
- -Cadmium plating: 500 hours
- -Nickel plating: 48 hours/96 hours
